Tri Axle 40FT Shipping Container Chassis

Name: Tri Axle 40FT Shipping Container Chassis
SKU: 0

The Shipping Container Chassis is a kind of loading and unloading equipment which is widely used in the field of logistics and transportation. It has the characteristics of stable structure, strong load capacity, easy operation, etc., and provides reliable support for the fast and efficient transportation of goods.

+8615163588677

manjumaoyi@sdmjtruck.com

+8615163588677

Contact Us

◉ PRODUCT DISPLAY

◉ Tri Axle 40FT Shipping Container Chassis

It is made of high strength steel, with high strength and stiffness, and can withstand the pressure of heavy cargo such as soybeans, steel and chemicals. The design of the skeleton structure makes the goods evenly distributed in the transportation process, effectively reduces the movement and shaking of the goods, and improves the transportation safety.

◉ PRODUCT PARAMETERS

Skeleton semi-trailer is mainly used in ships, ports, routes, roads, transfer stations, Bridges, tunnels, supporting multimodal transport logistics systems.

Specifically for all kinds of container transportation, customers can choose how many locks to replace according to their needs, and all accessories are selected by suppliers who have 20 years of experience in use, long-term reuse, with sufficient strength.

Features - Skeleton Semi Trailer

Highly robust structure steel with tensile and high load capacity, 40 ton loading capacity.

Heavy duty mechanical spring suspension for high loads requirements needs and handly bad road condition.

Length and width of skeleton avaiable custom made.

Air suspension and bogie suspension is an option.

8 units twist lock for carrying 20ft container and 40ft container.

20FT Skeleton Semi Trailer	40FT Skeleton Semi Trailer	45FT Skeleton Semi Trailer
Brand: Haiming	Brand: Haiming	Brand: Haiming
2Axles/3Axles	3Axles/4Axles	3Axles/4Axles
20ft Container Loading	1×40ft/2×20ft Container Loading	1×45ft/1×40ft/2×20ft Container Loading
Loading Capacity: 20-50 Tons	Loading Capacity: 30-80 Tons	Loading Capacity: 30-80 Tons
Type: Gooseneck or Tandem	Type: Gooseneck or Tandem	Type: Gooseneck or Tandem
Main Bean
Material: Q345/T700	Material: Q345/T700	Material: T700
Upper Plate Thickness: 12mm	Upper Plate Thickness: 14mm	Upper Plate Thickness: 10mm
Middle Plate Thickness: 6mm	Middle Plate Thickness: 6mm	Middle Plate Thickness: 5mm
Lower Plate Thickness: 12mm	Lower Plate Thickness: 16mm	Lower Plate Thickness: 10mm
Height: 500mm	Height: 500mm	Height: 420mm
Dimension
L×W×H: 7000mm×2480mm×1560mm	L×W×H: 12400mm×2480mm×1580mm	L×W×H: 13950mm×2500mm×1600mm
Axle
2/3 Axles×13 TonVEHCILE MASTER/FUWA/BPW	3/4 Axles×13 TonVEHCILE MASTER/FUWA/BPW	3/4 Axles×13/16 TonVEHCILE MASTER/FUWA/BPW
Tire
12R22.5 (8/12 Pieces)Linglong/ Triangle/DoubleCoin/Bridgestone	12R22.5 (12/16 Pieces)Linglong/ Triangle/DoubleCoin/Bridgestone	12R22.5 (12/16 Pieces)Linglong/ Triangle/DoubleCoin/Bridgestone
Rim
9.00×22.5 (8/12 Pieces)Steel/Aluminum	9.0×22.5 (12/16 Pieces)Steel/Aluminum	9.00×22.5 (12/16 Pieces)Steel/Aluminum
Leaf Spring
90mm×13mm×10 Pieces 90mm×16mm×10 Pieces	90mm×13mm×10 Pieces 90mm×16mm×10 Pieces	90mm×13mm×10 Pieces 90mm×16mm×10 Pieces
King Pin
#50 (2")/#90 (3.5")JOST/Other Brand	#50 (2")/#90 (3.5")JOST/Other Brand	#50 (2")/#90 (3.5")JOST/Other Brand
Landing Gear
28 Tons Two SpeedJOST/Other Brand	28 Tons Two SpeedJOST/Other Brand	28 Tons Two SpeedJOST/Other Brand
Twist Lock
4Sets	12Sets	12Sets
Painting
Electrophoresis Painting	Electrophoresis Painting	Electrophoresis Painting

◉ PACKAGING AND TRANSPORTATION

◉ FAQ

Q： What types of machinery do you supply?

A：

We supply a range of construction machinery and transport equipment, including trucks, construction vehicles, semi trailers, forklifts, excavators and other specialized equipment. Please contact us for the latest product availability.

Q： Can I get detailed specifications before placing an order?

A：

Yes. We can provide detailed product specifications, configurations, dimensions, performance information and other technical details based on your requirements.

Q： How do I choose the right machine for my project?

A：

Our sales team can recommend suitable equipment based on your application, working conditions, required capacity, budget and destination market.

Q： Are your machines suitable for different countries and working conditions?

A：

Yes. Equipment can be selected and configured according to different operating environments, project requirements and market conditions. Please share your requirements with us for a suitable recommendation.

Q： Can you provide product photos and videos?

A：

Yes. We can provide product photos, videos and relevant technical information to help you evaluate the equipment before ordering.

Q： How can I request a quotation?

A：

Simply send us the product name, required quantity, specifications and destination. Our team will review your requirements and provide a quotation.
